Click the frame parts together
The frame parts are made of lightweight aluminium. Just connect them with a click and the LED lights are also automatically connected.
Mounting the frame
The accompanying set up instruction shows which frame parts that should be connected with each other.
Extra long feet
Attach the feet to the frame before adding your fabric print. For this lightbox solution, extra long feet are used to ensure stability.
T connector where your monitor is attached
This shows the frame without the fabric, with the so called T connector in the middle where your monitor is attached.
Monitor holder unit
This monitor holder unit is attached to the T connector before applying your fabric print.
Monitor holder parts
The rest of the monitor holder parts, including locking pins for your TV/monitor.
Small cut-out for your monitor
Your printed fabric comes with a small hole for the monitor holder.
VESA mount
The VESA mount is attached after you have applied your fabric print. Supports VESA standard 75,100, 200, 300 & 400
Great light distribution with LED
Illuminated with LED light, placed in the top and bottom, to provide an even glow over the graphics. It has a low electric consumption - which is better for the environment. The LED light has a life expectancy of 100 000 hour. All electronic components are CE; UL certified.
Excellent fabric print
Your graphic is dye sub printed on a wrinkle-resistant stretch fabric with excellent print quality for brilliant backlit graphics.
Bag
The monitor holder units (including the support feet) are delivered in a sturdy nylon bag for easy transportation and storage.
Facts
Weight incl. nylonbag
80x160x8 cm - 14 kg
160x160x8 cm- 17,5 kg
240x160x8 cm- 20,5 kg
The support foot is 57 cm deep and there is a half foot available if you need to place the lightbox close to a wall
Nylonbag dimensions:
(160x80 cm) 95x36x30 cm
(160x160 & 160x240 cm) 95x36x36 cm
Weight incl. nylon bag
80x240x8 cm - 19 kg
160x240x8 cm - 21 kg
194x240x8 cm - 22 kg
240x240x8 cm - 24 kg
294x240x8 cm - 28 kg
401x240x8 cm - 42 kg
(delivered in two bags)
482x240x8 cm - 46 kg
(delivered in two bags)
562x240x8 cm - 50 kg
(delivered in two bags)
The support foot is 57 cm deep and there is a half foot available if you need to place the lightbox close to a wall.
Nylonbag dimension:
95x36x36 cm
Weight incl. nylon bag
80x240x8 cm - 19 kg
160x240x8 cm - 21 kg
194x240x8 cm - 22 kg
240x240x8 cm - 24 kg
294x240x8 cm - 28 kg
401x240x8 cm - 42 kg
(delivered in two bags)
482x240x8 cm - 46 kg
(delivered in two bags)
562x240x8 cm - 50 kg
(delivered in two bags)
The support foot is 57 cm deep and there is a half foot available if you need to place the lightbox close to a wall.
Nylonbag dimension:
95x36x36 cm
